Civil Engineering for Residential Subdivisions in Utah: Complete Planning Guide

Subdivision Design & Platting in Utah | Ludlow Engineering
4.977 Google reviews Subdivision design · Platting · Lot splits · Utah

Subdivision Design & Platting in Utah. Survey, Engineering and Plat From One Office.

From a one-lot split for family to a multi-phase subdivision with new streets, we survey the land, design the lots and improvements, prepare the plat, and stake it in the ground. 529 subdivisions and plats in our records since 2000, from Nephi and Mount Pleasant to Ephraim, Fillmore and Utah County.

Hawks Landing Plat A, a 16-lot residential subdivision plat in Ephraim, Utah, prepared by Ludlow Engineering
Hawks Landing Plat A, 16 lots · Ephraim · from our files
The short answer

What Does Subdivision Design & Platting Include?

Everything between raw ground and lots you can sell: a feasibility check of zoning, water and sewer; a boundary and topographic survey; a preliminary plat and improvement drawings for streets, grading, water and sewer; an engineer’s estimate for the bond; the final plat recorded with the county; and construction staking and lot corners once it’s built.

We do all of it in one Nephi office, so nothing gets lost between the surveyor and the engineer.

  • Our plats529 since 2000
  • Busiest countiesSanpete 279 · Juab 131
  • Starts withA boundary survey, from $1,025
  • QuoteFixed fee, in writing
01 · What we deliver

Nine Services, One Team, One Set of Survey Control

Pick the pieces you need, or hand us the whole project. Every drawing ties back to the same boundary and benchmarks.

01

Feasibility & concept plan

Zoning, lot size, frontage, access and utility service checked before you spend real money. A concept layout you can take to the city’s pre-application meeting.

02

Boundary survey

The outer boundary, section and block corners recovered and tied together. Every lot line on the plat depends on it. Boundary surveys start at $1,025.

03

Topographic & utility survey

Ground shape, ditches, fences, power, water and sewer mapped so streets and lots drain. 142 topo surveys in our records.

04

Preliminary plat

Lot layout, street widths, easements, dedications and phasing, drawn to the city’s checklist and submitted for review.

05

Improvement drawings

Street plan and profile, grading and drainage, water, sewer and storm drain, stamped by our PE. See water & sewer design.

06

Cost estimate for bonding

An engineer’s estimate of the public improvements, which most cities use to set the bond or escrow before they record the plat.

07

Final plat & recording

The signed plat with lot dimensions, monuments, easements, and the owner’s, surveyor’s and city certificates, ready for the county recorder.

08

Construction staking

Streets, curb, water and sewer staked from the same control the plat was built on. 55 staking jobs in our records.

09

Lot corners & as-builts

Lot corners set after recording, and as-built surveys the city needs to accept the improvements.

02 · Who we work with

From One Lot for Family to a Phased Development

Most of our subdivision clients fit one of these four. Each needs a different amount of engineering.

Landowners & families

Splitting off a lot for a child, selling part of the farm, or dividing an estate.

Developers

New streets, utilities and phases, from raw ground to accepted improvements.

  • Major & multi-phase subdivisions
  • Street, water & sewer design
  • Bonding estimates & staking
  • Land development & annexations
03 · Utah approvals

How Subdivisions Get Approved in Utah Today

The rules changed recently. Here’s what’s the same everywhere, and what your city or county still decides.

What state law changed

Under S.B. 174 (2023), Utah cities had to update their subdivision ordinances by the end of 2024. For single-family, duplex and townhome subdivisions, cities now:

  • Review through an administrative land use authority (staff or the planning commission), not the city council
  • Allow up to four review cycles in total, preliminary and final combined
  • Work to set review deadlines, with longer allowances in towns of 5,000 or fewer
  • May recommend, but not require, a pre-application meeting

Faster, more predictable review rewards a complete first submittal. That’s where an experienced surveyor and engineer save you time.

Source: Utah League of Cities and Towns, Subdivisions FAQ. Unincorporated land goes through the county; commercial subdivisions follow the local ordinance.

What your city still checks

  • Zoning: minimum lot size, width and frontage, and whether the use is allowed.
  • Water: culinary water connections, and in many Utah towns, water rights or shares turned over for each new lot.
  • Sewer or septic: sewer capacity, or septic approval from the local health department where there’s no sewer.
  • Access & fire: street width, turnarounds and fire hydrant spacing.
  • Irrigation ditches & canals: easements and piping requirements across new lots.
  • Flood zones & drainage: where storm water goes and whether lots sit in a mapped flood zone.
  • Annexation: land outside city limits that needs city services may have to be annexed first.

We check these during feasibility, before the plat is drawn, because they’re what most often changes the lot count.

We’re licensed surveyors and engineers, not attorneys. Deeds, title, water rights transfers and disputes belong with a Utah real estate attorney or title company.

04 · Real plats

Three Subdivisions From Our Files

Residential and commercial, surveyed, designed and platted in one office. Click any plat to enlarge it.

Hawks Landing Plat A, a 16-lot residential subdivision plat in Ephraim, Utah, by Ludlow Engineering
Residential · EphraimHawks Landing Plat A16 lots on 5.17 acres. 1.8 acres of new right-of-way dedicated to Ephraim City, a temporary turnaround for the next phase, and setback and easement details on every lot.Our scope: Boundary · plat · street dedication · phasing
Nebo Meadows, a 42-lot residential subdivision plat in Nephi, Utah
Residential · NephiNebo Meadows42 residential lots on 14.56 acres, with a new 60-foot public street, city utility easements and a road extension tying into the neighboring subdivision.Our scope: Boundary · topo · plat · street & utility layout
Reed Ridge, a six-lot commercial subdivision plat on Main Street in Nephi, Utah
Commercial · NephiReed RidgeSix commercial lots on 7.34 acres along Main Street, with shared 30-foot access and utility easements and a sign easement along the frontage.Our scope: Boundary · plat · shared access · easements
05 · Our record

529 Subdivisions and Plats Since 2000

Lot splits, minor and major subdivisions, plat amendments and annexations. Recent work, without client names.

279Sanpete County
131Juab County
74Utah County
14Millard County
  • Nephi · 2025–2026A four-lot subdivision with boundary, topo and utilities; a topo and subdivision; an agricultural split with an annexation plat; and subdivision lines redrawn on an older recorded plat.
  • Mount Pleasant · 2024–2026Concept, boundary, topo and utilities through the subdivision plat; an ALTA survey paired with a subdivision; plats with corner restaking; minor subdivisions and lot splits.
  • Spring City · 2025Survey, subdivision and road design, and a three-lot minor subdivision.
  • Ephraim & Manti · 2024–2026Subdivisions in both cities, a three-lot subdivision, and a condominium subdivision plat with its site plan.
  • Utah County · 2024–2026Salem: boundary, topo, utilities, subdivision plat and design. Provo: topo, utilities and subdivision. Plus subdivisions in Orem, Spanish Fork, Payson and Santaquin.
  • Fillmore & Oak City · 2024–2026A subdivision with apartment and commercial site plans, an annexation, platting with new descriptions, and an annexation with a subdivision concept.
  • Moroni, Wales, Fairview, Gunnison & IndianolaSubdivision plats with restaking, one-lot and minor subdivisions, and a five-acre subdivision with easements.
  • Since 2000529 subdivisions and plats in our records: Sanpete 279, Juab 131, Utah County 74, Millard 14.
06 · Cost & timeline

What Subdividing Land Costs in Utah

Every subdivision is quoted as a fixed fee in writing. These are the pieces most quotes are built from. City application, review, bonding and recording fees are separate.

WorkTypical costNotes
Boundary survey, recorded lot$1,025–$1,800Lot splits on an existing subdivision lot
Boundary survey, 1–5 acres$2,000–$4,000Most minor subdivisions
Boundary survey, 5–20 acres$3,500–$6,500Larger subdivisions
Boundary survey, 20+ acres$5,000+Farm ground & phased projects
Topographic survey$1,500–$4,500Needed for streets, grading & utilities
Grading & drainage plan$2,000–$6,500Per phase, depending on size
Plat & improvement drawingsQuoted by scopeLot count, streets, water & sewer
Construction staking$1,500–$5,500+Streets, curb & utilities
As-built survey$500–$8,000+For city acceptance of improvements
A few monthsLot split or minor subdivision on an existing street
6–12+ monthsSubdivision with new streets & utilities
1–4 weeksBoundary or topo survey to start
Per phaseLarger projects, platted & built in phases

More on pricing: 2026 land survey costs · how long a survey takes

07 · Who does the work

The Engineer and Surveyor Behind Your Plat

Licensed in Utah and in the same office, so questions get answered the same day they come up.

J. Brett Ludlow, PE, civil engineer, at his desk in Nephi

J. Brett Ludlow, PE

Civil engineer · Ludlow Engineering, Nephi

Brett designs the streets, grading, water, sewer and storm drainage on our subdivisions and stamps the improvement drawings cities review. He also prepares the engineer’s cost estimates used for bonding.

Our plats are signed by Daryl Penrod, PLS (Utah No. 5331527), and our survey crews stake the improvements and set the lot corners. Meet the whole team.

08 · Lessons

What Keeps a Subdivision on Schedule

Habits from five decades of platting land in central Utah.

Lesson 01

Find the water first.

Water connections and water rights or shares decide more lot counts than zoning does. We check them before drawing a single lot.

Lesson 02

Survey before you sketch.

A concept drawn on a county parcel map can be off by feet or more. The boundary survey comes first so the layout fits the ground.

Lesson 03

Submit it complete.

With a limit on review cycles, a complete first submittal is the fastest path to approval. Missing pieces cost a whole cycle.

Lesson 04

Plan the next phase now.

Stub the utilities and plan the street connection for the next phase, so phase two doesn’t mean tearing up phase one.

09 · Before you call

Five Things That Make the First Call Count

You don’t need all of them. Even just the parcel number is enough to start.

  1. Parcel number or address. We pull the deed, plats and nearby surveys from the county.
  2. How many lots you’re hoping for, and roughly how big.
  3. Water and sewer: whether city lines are nearby, and any water rights or shares you hold.
  4. What the city has told you, if you’ve already talked to the planner.
  5. Your timeline: selling, building, or planning ahead.

Talk to the Nephi Office

Ask for a subdivision quote and we’ll take it from there.

(435) 623-0897
10 · Direct answers

Subdivision Questions, Answered.

How much does it cost to subdivide land in Utah?

It depends on the number of lots, whether new streets and utilities are needed, and your city's requirements, so we quote each subdivision as a fixed fee in writing. The boundary survey that starts it runs from $1,025 for a recorded lot, $2,000–$4,000 for 1–5 acres and $3,500–$6,500 for 5–20 acres. A topographic survey runs $1,500–$4,500. City application, review and recording fees are separate.

How long does a subdivision take?

A lot split or minor subdivision on an existing street often takes a few months from survey to recording. A subdivision with new streets and utilities often takes six months to a year or more, mostly in city review and construction of improvements.

Who approves a subdivision in Utah now?

Since 2024, state law (S.B. 174, 2023) has required Utah cities to review single-family, duplex and townhome subdivisions through an administrative land use authority, such as staff or the planning commission, rather than the city council, with a limit on review cycles and set review deadlines. Unincorporated land goes through the county. Commercial subdivisions follow the local ordinance.

Can you handle the whole thing, survey through recording?

Yes. Our surveyors and our civil engineer, J. Brett Ludlow, PE, work in the same Nephi office, so the boundary, topo, plat, improvement drawings, bonding estimate, staking and lot corners all come from one team and one set of survey control.

Do I need a subdivision or just a lot split?

It depends on the city or county. Some allow a simple split of one parcel into two with new descriptions; others require a minor subdivision plat. Send us the parcel number and we'll check your local ordinance.

What about water rights and sewer?

Many Utah cities require water rights or shares for each new lot, and sewer capacity or septic approval. These are often the biggest surprises in a subdivision, so we check them during feasibility, before the plat is drawn.

Can a subdivision be built in phases?

Yes. Larger subdivisions are often platted and built in phases, with temporary turnarounds and utility stubs for the next phase, like Hawks Landing Plat A in Ephraim.

Do you plat condominiums and PUDs?

Yes. We prepare condominium plats with units and common areas, and commercial subdivisions with shared access and utility easements.

What should I have ready when I call?

The parcel number or address, how many lots you hope to create, whether city water and sewer are nearby, and any conversations you've had with the city. That's enough for us to tell you what's realistic and quote it.

Want the step-by-step? Read our complete guide to subdivision plats.

Utah PLS & PE · Since 1975

Ready to Turn Your Land Into Lots?

Call or send the parcel number and how many lots you want. We’ll check the records, tell you what your city requires, and quote a fixed fee.
